ERCOT Methodology

Modo Energy provides benchmark data for battery energy storage systems across global energy markets, applying a standardized mathematical methodology to ensure consistency and transparency across all produced Indices.

1. Introduction

The Modo Energy Electric Reliability Council of Texas (ERCOT) Methodology Framework outlines the calculation and construction of Modo Energy’s battery energy storage Indices in ERCOT. This document provides detailed insights into:

• the inclusion criteria for assets;
• the components that make up published revenues; and
• the methodologies employed;

to ensure accurate and reliable benchmarking for ERCOT’s battery energy storage sector.

1.1 Representation

Modo Energy’s Indices are designed to track the performance of grid-scale lithium-ion battery energy storage systems in ERCOT. Since battery energy storage projects differ in their characteristics, Indices are also tailored to highlight and assess the revenue performance of assets with specific attributes, such as system duration.

2. Index Construction

2.1 ME BESS ERCOT Indices

Modo Energy currently produces three Indices which track the performance of battery energy storage systems in ERCOT. These are:

• ME BESS ERCOT: Includes all qualifying assets in ERCOT.
• ME BESS ERCOT (1H): Includes assets with a duration of less than 1.5 hours.
• ME BESS ERCOT (2H): Includes assets with a duration of more than 1.5 hours and less than 2.5 hours.

2.2 Inclusion Criteria

Assets must meet specific criteria to be included in the indices:

• Commercially operational: Assets must be approved for commercial operations by ERCOT as defined in section 2.2.1 below.
  • Assets no longer included in disclosure data are considered decommissioned and excluded.
• Metering: Assets must not share a meter with co-located assets.

2.2.1 Commercially Operational

An asset is considered commercially operational on the first date of market activity following its commissioning date, which is reported in ERCOT's monthly GIS report. Market activity is defined as either the first settlement of metered net energy or the first awarded Day-Ahead contract.

Only market activity from this point onwards is used in daily index calculations, and any activity before the commissioning date is excluded.

2.3 Index calculation methodology

The index calculation follows a clearly defined, rule-based methodology with no discretionary adjustments, ensuring transparency, consistency, and reliability.

The Index value is calculated daily by dividing the sum of revenues of all commercially operational assets (see section 2.2.1) against the sum of their total rated power or energy capacity (see section 2.3.1 for divisor details). This calculation produces an Index value representing a normalized measure of average revenue per unit of capacity for battery energy storage systems in ERCOT.

2.3.1 Divisor

The divisor is a fundamental component of Modo Energy’s BESS ERCOT Indices, acting as a normalization factor to ensure assets of all sizes can be benchmarked against the produced Indices. It is calculated daily by summing the total rated power or energy capacity of all commercially operational assets (see section 2.2.1), with rated power based on an asset’s nameplate capacity rather than its grid connection.

The divisor is recalculated daily to reflect changes in commercially operational capacity, ensuring the Index continues to represent assets actively contributing to revenue generation.

2.4 Index value representation

All Index values are reported in terms of net revenues per settlement period. Revenue and Index values can be represented using the following units:

• USD/MW/hour (hourly): Calculated by dividing the total index value for the assessed period by the total number of hours in the period (days × 24).
• USD/MW: Calculated by summing the total index value for the assessed period.
• USD/MW/year (annualized): Calculated by dividing the total index value for the assessed period by the number of days in the period and multiplying by 365 to project an annualised value.

3. Revenue Components

3.1 Revenue Components of Indices

This section details the key revenue streams incorporated into the ME BESS ERCOT Indices, reflecting the primary revenue opportunities available to battery energy storage systems in ERCOT’s wholesale markets.

The revenue components included in Modo Energy’s ERCOT Indices are:

• Day-Ahead Energy Market: The day-ahead energy market involves market participants submitting bids and offers to contract to deliver or receive power the following day.
• Real-Time Energy Market: The real-time energy market operates continuously, allowing for the purchase and sale of electricity on a real-time basis. This market ensures that electricity supply matches demand instantaneously, in which power prices are calculated every 5 minutes by ERCOT’s Security-Constrained Economic Dispatch process.
• Ancillary Services: Ancillary services are crucial for maintaining grid stability and reliability, and are procured by ERCOT in the Day-Ahead Market. These services include:
  • Regulation Up and Regulation Down: Real-time adjustments to generation to maintain system frequency.
  • Responsive Reserve Service (RRS): Spinning reserves for rapid response to sudden demand changes or outages. Help bring frequency back up to 60 Hz when it falls below the deadband.
  • Non-Spinning Reserve Service (NSRS): Quick-start (30-minute) reserves for unexpected demand or generation shortfalls.
  • ERCOT Contingency Reserve Service (ECRS): Additional quick-start reserves for sudden demand spikes and rapid changes in supply. Also utilized to provide additional capacity for frequency response in the event of a large frequency event (like a large unit trip).

4. Data Sources and Methodology

4.1 Data Inputs and Visibility

To ensure accuracy, Modo Energy only includes utility-scale battery energy storage system resources included in ERCOT disclosure reports in its Indices calculations. These resources are identified in data where the resource type is reported as “PWRSTR” (Power Storage). Data from EIA is also taken to provide further context on asset details such as energy capacity and clarification of nameplate capacity.

4.2 Use of Discretion

Modo Energy applies discretion strictly within predefined parameters to ensure consistency and transparency. Discretion is exercised only in the following circumstances:

• Asset sizing (MW or MWh): If publicly available data is insufficient, information from credible third-party sources may be considered for validation.
• Selection of data sources: The most appropriate publicly available sources are selected based on their reliability and relevance to BESS operations.

All discretionary decisions are made in accordance with the benchmark methodology and subject to internal governance oversight to ensure impartiality and compliance with regulatory standards.

4.3 Revenue Calculation Methodology

Battery energy storage systems in ERCOT operate as both generation and load resources. In our Index calculations, we combine revenue data from both resource types to determine a net revenue for each market, which is then allocated to each specific battery energy storage asset.

4.3.1 Day-Ahead Energy Market Revenue Calculation

Revenues from day-ahead energy contracts are calculated based on the awarded contract volume (MW) multiplied by the settlement point price ($/MW) at the resource node for each generation resource. This revenue calculation is in accordance with the method outlined for day-ahead energy resource revenues outlined in the ERCOT protocol 4.6.2.2.

Load resources can not bid for day-ahead energy awards in ERCOT. Negative day-ahead energy revenues are attributed to energy bids at the settlement point where a system is located. Only energy bids placed by the same Qualified-Scheduling-Entity (QSE) and Decision-Making-Entity (DME) as the resource at the node are considered. Any power imported from the load side of the resource is assigned day-ahead energy revenues if a corresponding energy bid exists. If no power is imported but an energy bid is present, the transaction is considered virtual, and no revenues are attributed to the asset.

4.3.2 Real-Time Energy Market Revenue Calculation

Real-time energy revenues are calculated by using the net physical position between both the load and generation resources of an asset, comparing this to any contracted position in the day-ahead market, and then multiplying this difference by the real-time settlement point price at the resource node for each 15-minute interval period. This difference between an asset's net physical operation and its Day-Ahead position is also known as the Real-Time power imbalance, which is used by ERCOT in settlement.

The volume physically dispatched on the generation side of the resource is determined using settlement-metered net energy volume data provided by ERCOT. For the load resource portion of the battery, the telemetered net output (MW) provided in SCED load resource disclosure data is used. This net output value (MW) is multiplied by 0.25 to estimate an energy volume (MWh) value for that given interval period. This assumes the telemetered net output value (MW) provided by ERCOT is an average value for any given interval period.

The real-time settlement point price at the resource node comprises the locational marginal price (LMP) calculated by SCED and additional ERCOT price adders. For individual asset revenue calculations, the Operational Reserve Demand Curve (ORDC) is treated as a distinct revenue stream, separate from other real-time revenues. In the context of the calculated indices, ORDC revenues fall under the general category of real-time energy revenues.

The revenue calculation described is per the method outlined for Real-Time Energy Imbalance Payment or Charge at a Resource Node as outlined in ERCOT protocol 6.6.3.1.

4.3.3 Ancillary Services Revenue Calculation

Revenues from ancillary service contracts are calculated based on the responsibility (MW) reported to SCED by a resource multiplied by the hourly clearing price ($/MW) for that given service. This revenue calculation follows the method outlined for day-ahead ancillary service revenues outlined in the ERCOT protocol 4.6.4.1.

The day-ahead ancillary service revenue, as outlined in the ERCOT protocol, is settled for a Qualified Scheduling Entity (QSE). QSEs can trade and allocate their total awarded ancillary services among their resources bilaterally. Instead of using the awarded amount in the day-ahead market as per the protocol, the responsibility reported to SCED by resources in real-time is used.

This real-time responsibility can sometimes differ from the awarded capacity in the day-ahead market. This approach ensures that our Indices accurately track the performance of battery energy storage in ERCOT.

Any energy dispatch resulting from utilization in providing an ancillary service is included in the real-time energy revenue calculation. Awards from the supplementary ancillary service market are not considered.

4.4 Updates and Revisions

The Indices are updated daily to reflect the most current data. In cases, where data available after provides more accuracy, Index calculations are backdated to include this.

5. Governance and Compliance

5.1 Transparency

Detailed explanations of calculation methodologies and revenue components are provided to ensure transparency.

5.2 Stakeholder Engagement

Feedback from stakeholders is actively sought - and incorporated into methodology updates. This includes the use of real financial and operational data for internal benchmarking purposes to validate our estimations. Reviews are conducted by a team of experts to maintain accuracy and relevance.

6. Methodology Changes

6.1 Review and Update Process

The methodology is overseen by a dedicated team of analysts to ensure compliance and best practices.

The methodology is reviewed periodically to ensure it remains up-to-date with market conditions and regulatory changes. With the introduction of new products (e.g. markets or services in which battery energy storage systems can earn revenues) and the retirement of old ones, the methodology is revised and updated to encompass all market opportunities for battery energy storage assets, provided data is available for assessment.

6.2 Notification of Changes

Significant changes to the methodology are communicated to stakeholders in advance, with detailed explanations provided to ensure understanding and transparency. Historical changes are documented and archived in the appendix of this methodology.

7. Consistency and Continuity

7.1 Quality Assurance

Rigorous quality assurance processes are in place to ensure the accuracy and reliability of benchmark calculations. This includes regular audits and validation of data sources and calculation methods.

7.2 Data Integrity

Data integrity is maintained through strict data management protocols, including secure data storage, regular backups, and robust data validation procedures.

7.3 Continuity Planning

Business continuity planning ensures that benchmark calculations can continue uninterrupted in the event of unexpected disruptions. This includes backup systems and contingency plans for data and operational processes.

Appendix I

Methodology changes

Methodology changes since Dec 3, 2023, are as follows:

Appendix II

Throughput and cycling calculations

Throughput and cycling do not influence index calculations but are displayed on the terminal to provide additional insights into battery operations in ERCOT.

Throughput measures the energy exported by an asset during market operations. It is calculated by taking the net metered (MW) volume, derived from the difference between the telemetered values of an asset’s generation and load resources, and multiplying it by 0.25 to convert it into energy (MWh) for each 15-minute settlement interval.

Cycling measures how often an asset utilizes its energy capacity over a given period. It is calculated using the formula:

• Total Energy Throughput represents the total exported energy calculated as described above.
• Energy Capacity refers to the asset’s rated energy storage capacity (in MWh).
• Total Days Analyzed denotes the period over which throughput is assessed.

Appendix III

Availability calculations

Availability does not impact index calculations but is shown on the terminal to provide additional insights into battery operations in ERCOT.

Availability measures the number and percentage of hours a battery asset is reported as available to operate based on its resource status in ERCOT’s 60-Day SCED Disclosure Reports. Since ERCOT models batteries as both generation and load resources, availability is determined by analyzing both data sets.

An asset is considered unavailable if its status is recorded as any of the following in the reports:

• OUT – Out of service.
• OUTL – Out due to limits.
• ONTEST – Under testing.
• Not provided – Status missing in the data.

If none of these statuses apply, the asset is marked as available for that period.

Availability is assessed for each 15-minute settlement interval. A battery is considered available if either its generation or load resource is available. If both are unavailable, the asset is classified as unavailable for that period.

Appendix IV

ME ERCOT BESS (NOWCAST)

The ME ERCOT BESS (NOWCAST) assesses the performance of battery energy storage systems (BESS) in ERCOT, offering market participants an estimated view of battery energy storage system operations, revenue potential, and performance across key market components, including day-ahead and real-time energy markets and ancillary services. It aims to enhance transparency and provide performance estimates to bridge the gap in the 60-day disclosure data from ERCOT, to provide real-time insight into battery energy storage revenues.

Energy Revenues

To calculate energy revenues, Modo Energy estimates a system-wide battery price and multiplies this value by the aggregated net output of battery resources.

System-wide Battery Price

The system-wide battery price is determined by averaging the prices at all battery resource nodes within ERCOT. This aggregated approach reflects the collective operations of battery resources and informs the ERCOT Battery Benchmark.

Assumptions

Based on Modo's operational data, batteries typically import power when prices are low and export when prices are high. To calculate energy revenues, we average the top 50% of prices during export periods and the bottom 50% during import periods, using the corresponding MW values for each interval, then sum these values.

All energy revenues are based on real-time energy prices, as Day-Ahead market revenues have contributed only 0.62% of total asset revenues over the past three years (as of May 30, 2024).

Ancillary Service Revenues

To calculate ancillary service revenues, we estimate battery participation in each service and multiply it by the market clearing prices.

Ancillary Services Procured

The volume of ancillary services procured by ERCOT is sourced from the Ancillary Service Requirements dataset.

Ancillary Services Awarded to Batteries

Battery participation in ancillary services is estimated by taking the rolling 30-day average of service capacity awarded to batteries during each delivery hour. This battery participation rate, based on proprietary data from our ME BESS ERCOT calculations, is then multiplied by the total ancillary services procured.

Assumptions

Due to ERCOT's 2-day delay in publishing ancillary services volumes, we rely on the service requirements dataset for procurement estimates, assuming full capacity is achieved in day-ahead auctions. There were only 6 days in 2023 where more than 200 MW were procured outside the Day-Ahead market.

A rolling 30-day average of battery participation smooths daily fluctuations, reducing noise in revenue estimates. Despite minor errors from daily variations, our analysis shows a 99.7% correlation between ancillary service revenues in the ERCOT Battery Benchmark and the ME BESS ERCOT for the period between December 6, 2023, and May 30, 2024.

Accuracy

Using values from the ERCOT Battery Benchmark from December 6, 2023 - we found a 99.8% correlation with the ME BESS ERCOT and a median absolute daily error of $19/MW.
