SPP Methodology

Modo Energy provides benchmark data for battery energy storage systems across global energy markets, applying a standardized methodology to ensure consistency and transparency across all produced Indices.

1. Introduction

The Modo Energy SPP Methodology Framework sets out how Modo Energy's battery energy storage benchmarks for the Southwest Power Pool (SPP) are constructed. It explains:

• what the Benchmarks measure and the justification behind the approach (§1);
• the key terms used (§2);
• the representative asset and how its values are calculated (§3);
• the revenue components included (§4);
• the data inputs, fallbacks, and minimum data requirements (§5);
• the optimization engine (§6);
• how expert judgement is exercised (§7);
• how the Benchmarks are determined when data is missing or markets are disrupted (§8);
• when published values may be revised (§9);
• how the methodology is reviewed and changed (§10-11);
• and the Benchmarks' limitations (§12).

1.1 What the SPP Benchmarks measure

The ME vBESS SPP Benchmarks measure the simulated market revenue of a representative grid-scale lithium-ion BESS in SPP, expressed per MW of rated power. The family of benchmarks is grouped by system duration so revenues can be compared across battery configurations. Each Benchmark reflects revenue a representative asset could earn from SPP's energy and ancillary service markets rather than a measurement of any individual operator.

1.2 Why SPP requires a simulated benchmark

The SPP benchmark is simulated, not measured.

SPP does not publish the asset-level data needed to account for the operations and revenues of individual batteries on its grid. It publishes market clearing prices for energy (locational marginal prices, LMPs) and for each ancillary service (marginal clearing prices), but not per-asset dispatch, rewards, or revenues. By contrast, ERCOT publishes the ancillary service awards and telemetered net output of individual units, which allows Modo Energy to construct asset-level benchmarks for realized revenues.

1.3 Why this method is used

In the absence of asset-level data, Modo Energy estimates what a battery could earn in SPP by simulating the optimal trading strategy against the historical prices SPP publishes. The trading strategy is the output of Modo Energy's Global Dispatch Model (GDM) — a mixed-integer linear program (MILP) that maximizes battery revenue subject to market rules and physical constraints (§6). This approach:

• uses only public SPP price data, so that every input can be traced to an SPP publication;
• applies a fixed, disclosed asset specification, so that changes in Benchmark values reflect changes in market prices rather than changes in the asset or its operator; and
• uses the same model as Modo Energy's simulated benchmarks in other markets, maintaining consistency across all such Benchmarks.

The model optimizes with perfect knowledge of the day's prices, so its raw output can overstate what a real operator would earn. A calibration factor is applied to account for this (§6.6).

2. Definitions

3. Benchmark Construction

This section details the parameters that define the simulated battery in a Modo Energy virtual asset benchmark. The default values for those parameters in the ME vBESS SPP Benchmarks are also provided.

3.1 The ME vBESS SPP Benchmarks

Modo Energy produces a family of nine benchmarks for SPP. The benchmarks vary in the duration and settlement location of the simulated battery:

• The durations are: 1-, 2-, and 4-hours
• The settlement locations are the three aggregate pricing hubs in SPP: the south (SPPSOUTH_HUB), north (SPPNORTH_HUB), and west (SWPW_HUB) hubs.

The naming convention for this family of benchmarks is ME vBESS SPP [settlement location] ([duration]H) — for example, the 2-hour benchmark for the western hub is "ME vBESS SPP West (2H)".

This family of benchmarks are produced using the methodology described in this document, with a common set of operational and behavioral parameters. These parameters are specified below.

3.2 Representative vBESS specification

These parameters are set by Modo Energy, and are under the purview of the US modeling team. They define the representative asset and the behavior of the dispatch model. No input data (prices) are modified.

All parameters listed in §3.1 and §3.2 are customizable in user-defined vBESS benchmarks, with the exception of AS expected throughput and calibration factor.

3.3 How the Benchmark is calculated

For each operating day, the benchmark is calculated as follows:

1. Run the GDM for the day using the representative battery (§3.2) and the input data (§5).
2. Compute the revenues earned in each modeled market, in nominal USD, as the cleared price multiplied by the simulated position in each interval.
3. Multiply the revenue earned in each market by the calibration factor (§6.6).
4. Sum revenue across markets and divide by the asset's rated power to arrive at the USD/MW value of the Benchmark for the operating day.

Values for longer periods (a month, a week) are the sum of the daily values in that period.

3.4 Benchmark value representation

All Benchmark values are reported as net revenues per unit of rated power, in the following units:

• USD/MW/year (annualized): total revenue earned in a period, divided by the number of days in the period and multiplied by 365.
• USD/MW/hour (hourly): total revenue earned in a period, divided by the number of hours in that period.

In both the Modo Energy Terminal and Modo Energy API, users can optionally normalize by the battery's energy capacity. The headline representation remains the rated power-normalized value.

3.5 Publication cadence

The Benchmarks are updated daily. Modo Energy ingests SPP day-ahead and real-time energy and ancillary service clearing prices and publishes for the most recent operating day for which the minimum data in §5.5 is available, after a short lag to allow for SPP settlement and late postings.

3.6 Market evolution reflected in the Benchmark

4. Revenue Components

Modo Energy's virtual asset BESS benchmarks for SPP only consider wholesale revenue opportunities: energy and ancillary service. Resource Adequacy contracts, PPAs, and other capacity-provision like agreements are not included.

4.1 Revenue components included in the Benchmark

All ancillary products are capacity products: the battery is paid per MW of reserve held. Energy delivered when a service is deployed moves the battery's state of charge and counts toward cycling (§6.5), but only the capacity payment is counted as revenue.

4.2 Excluded revenues and costs

• Regulation mileage payments: real-time regulation mileage is paid per MW of movement rather than per MW of capacity; not modeled.
• Energy settlement of ancillary deployments: deployed energy affects SOC but is not separately settled.
• Capacity accreditation / resource adequacy payments: not a continuously cleared, publicly priced market product.
• Transmission congestion rights / congestion hedging: portfolio-specific; not modeled.
• Curtailment compensation: site-specific; not modeled.
• Network / transmission access charges: site-specific; set to zero.
• Bilateral contracts (PPAs, tolls, floors): not modeled.
• Operator fees, warranty, O&M: the Benchmark reports gross market revenue, not net of operating costs.

5. Data Inputs

5.1 Sources

The Benchmark uses four pricing datasets, all published by SPP. No other data sources are used for prices.

In addition, the model uses the parameters in §3.2 and a mapping published by SPP from pricing nodes to balancing areas, which determines the reserve zone for each settlement location.

5.2 Settlement locations and reserve zones

LMPs are nodal; ancillary service prices clear by reserve zone. Modo Energy observes no dispersion in ancillary service prices between reserve zones within a balancing area, so prices are taken at the balancing area level (SPP or SWPW).

User-created custom benchmarks can use settlement locations other than one of the three hubs. In these circumstances, DA LMP data is used to map from settlement location to the appropriate reserve zone. Beginning April 2026, that dataset added a "BAA" column that enables this mapping.

5.3 How inputs are combined

• All inputs are aligned to a common 5-minute grid in SPP local time. Hourly day-ahead prices apply to each 5-minute interval within their hour.
• Energy and ancillary prices are used as published by SPP. Modo Energy does not cap, filter or adjust prices, including during scarcity events.
• Revenue from each market is computed in the course of the optimization problem and then summed across periods as appropriate (§3.3).

5.4 Expected throughput of ancillary services

SPP does not publish per-service activation data suitable for the representative asset. The model applies fixed expected-throughput values to translate ancillary capacity held into energy that moves SOC and counts toward cycling (§6.5). The values are derived from ERCOT, where activation is observable, reduced by about 40% for regulation and about 90% for reserve products. They do not vary by time of day.

5.5 Data priority, fallbacks, and minimum data

• Priority. SPP-published prices are the only price source.
• Isolated gaps. Where a single interval is missing from an otherwise complete dataset, the value from the preceding interval is used (or, at the start of a day, the following interval).
• Minimum data. A Benchmark value is only determined for an operating day when all four datasets in §5.1 are available for that day at the settlement location and reserve zone. If any dataset is absent for the day, no value is published for that day until the data becomes available.

6. Modeling Methodology

6.1 What the model solves

The GDM answers one question: given the prices observed on a given day and the physical and regulatory limits of the asset, what is the highest revenue a well-run battery could have earned?

It allocates the battery's power and stored energy across energy (day-ahead and real-time) and ancillary capacity (Regulation Up/Down, Spinning, Supplemental, Ramp Capability Up/Down and Uncertainty Up). Revenue is the sum of these streams net of charging cost, subject to the constraints in §6.3–6.5.

6.2 Two-step co-optimization

1. Day-ahead step (60-minute granularity): day-ahead energy and the seven ancillary products are optimized together, mirroring SPP's co-optimized day-ahead market. The resulting positions are committed.
2. Real-time step (5-minute granularity): holding the day-ahead positions fixed, the model optimizes real-time energy and the seven real-time ancillary products within the asset's remaining headroom.

Each step covers one operating day. The model has perfect foresight of energy and ancillary prices over the operating day.

6.3 Market stacking and physical limits

1. Power headroom: the sum of discharging ancillary positions (Regulation Up, Spinning, Supplemental, Ramp Up, Uncertainty Up) cannot exceed rated power, and nor can the sum of charging positions (Regulation Down, Ramp Down).
2. Energy headroom: discharging ancillary positions must be backed by enough stored energy, and charging positions by enough empty capacity, to deliver at full power for 1 hour (day-ahead products) or 5 minutes (real-time products).
3. Grid limits: combined charge and discharge cannot exceed the 100 MW import and export limits.
4. Daily cycling cap: total discharge throughput per day, including energy delivered through ancillary deployment, cannot exceed 1.0 cycles of usable capacity.

6.4 The battery's physical arrangement

• Round-trip efficiency (88%) is applied to charging: 1 MWh drawn stores 0.88 MWh.
• State of charge in each interval equals the previous level plus charging (net of efficiency) minus discharging, plus the expected energy flow from ancillary deployment (§6.5). The net flow within an interval is used, so offsetting trades within an interval incur no efficiency loss.
• SOC window is 0%–100%, starting and ending each operating day at 0%.
• Degradation is disabled.

6.5 Capacity vs deployed energy

The battery is paid the cleared capacity price (USD/MW/h) for each MW of ancillary capacity held. Holding capacity reduces the power and energy available to the energy markets. The energy actually deployed against a capacity award varies by asset, day and time, and is not observable in SPP public data. The model therefore moves SOC by the held capacity multiplied by the expected throughput for that service (§5.4). That energy counts toward cycling but is not separately remunerated.

6.6 Revenue calibration

A flat calibration factor of 80% is applied to simulated revenue from every market. The factor accounts for the gap between perfect-foresight modeled revenue and what a real battery earns, which has three sources:

• Foresight: the model sees prices a real trader does not have when offers are submitted.
• Availability: real assets have outages and maintenance; the representative asset is always available.
• Execution: trading frictions and slippage.

The value of 80% is informed by comparing perfect-foresight GDM revenues with realized revenues in markets where asset-level data is published: ERCOT and Great Britain. Because the same factor applies to every revenue stream, it does not change the trade-offs between markets in the optimization; it scales the result.

7. Expert Judgement

SPP does not publish sufficient data to precisely model all aspects of a battery's operations. Within these gaps, expert judgement and market knowledge are used in place of empirical data. This section documents the modeling assumptions that inform the ME vBESS SPP Benchmarks.

7.1 Where judgement is exercised

The Benchmark is determined by the model from published prices; there is no discretionary adjustment of individual daily values. Expert judgment is exercised in setting the methodology itself, specifically:

• the representative asset specification (§3.2);
• the choice of settlement locations (§5.2);
• the ancillary expected-throughput values (§5.4); and
• the calibration factor (§6.6).

7.2 Keeping judgment consistent

These parameters are fixed in the GDM's version-controlled codebase and applied identically to every operating day and every SPP Benchmark. A parameter is changed only through a code change that is reviewed by a member of Modo Energy's modeling team other than its author and passes automated tests before release. Changes to parameters are treated as methodology changes under §11.

8. Market stress, disruption and missing data

Modo Energy's current practice is:

• Late or missing data. Where SPP data for an operating day is late or incomplete, Modo Energy waits for the data rather than estimating it. No value is published for that day until the minimum data in §5.5 is available.
• Extreme prices. Prices during scarcity, stress or other extreme events are used as published. The Benchmark is intended to reflect those conditions, so they are not removed or capped.

9. Revisions to published values

Published values may be revised, for example where:

• An error is identified in Modo Energy's processing of the input data; or
• A methodology change (§11) is applied to historical periods.

10. Methodology review

The methodology is reviewed internally by Modo Energy, including when SPP changes its market design, when new data becomes available (for example, SPP-specific ancillary activation data or new settlement locations), or when changes are made to the GDM. Any changes that result from a review are made under §11.

11. Methodology changes

Changes are classified as material or non-material. A change is material where it may meaningfully affect benchmark values, the inputs used, or what the benchmark measures. Material changes are announced with not less than 30 days' written notice before they take effect, together with an impact analysis.

Non-material changes are corrections and clarifications that do not alter the substance of the methodology. They may be made without prior consultation and are disclosed as soon as practicable.

Emergency changes needed to protect the integrity of the benchmark or to comply with law may be made without prior consultation, with notice given as promptly as circumstances permit.

All changes are recorded, with their effective date, in the change log (Appendix I).

12. Limitations

• Simulated, not observed. The Benchmark is not derived from transactions or the revenues of any real asset in SPP, and cannot be validated directly against SPP asset revenues because SPP does not publish them.
• Foresight and calibration. The model optimizes with perfect foresight. The 80% calibration factor is a single flat value derived from ERCOT and Great Britain, not from SPP. Actual foresight losses vary over time and between markets.
• Price-taker assumption. The representative asset is assumed not to affect prices and can clear its full offered capacity in any market. SPP's ancillary requirements are small relative to the energy market, so in practice a single asset, or a growing battery fleet, may not clear the volumes modeled or may depress clearing prices. The Benchmark may overstate ancillary revenue where markets are thin or concentrated.
• Ancillary activation. Expected-throughput values are derived from ERCOT, not SPP, and do not vary by time of day.
• Location. Benchmarks use hub prices. Assets at individual nodes face different congestion and losses and may earn materially different energy revenue.
• Short history. Ancillary data begins in January 2023 and SWPW data in April 2026, which limits long-run comparison.
• Reserve zone mapping. A node's most recent reserve zone is applied across the whole history (§5.5).
• Asset assumptions. The asset is always available, does not degrade, and starts and ends each day empty. Real assets differ on each point.
• Excluded revenues. The revenues and costs listed in §4.2 are not captured.
